OUCO Port Gantry Cranes, 3.2 Ton - 40 Ton
OUCO Port Gantry Cranes is an ideal solution for efficient loading and unloading of goods and containers in ports and open storage yards. These cranes, equipped with grabs, hooks, and spreaders, boast a lifting capacity of up to 40 tons, maintaining consistent capacity regardless of amplitude. The high working speed ensures exceptional productivity.
Our gantry cranes for shipbuilding are tailored for ship platforms, shipyards, and on-site operations. They excel in tasks like hull splicing and equipment mooring, utilizing hooks for lifting objects. With a maximum lifting capacity of 300 tons, these cranes offer variable lifting speeds, allowing for increased speed when handling lighter loads. Micro-actuators can be incorporated into the working mechanism to meet specific installation requirements.
For operations requiring larger lifting heights and extensive reach, our gantry cranes with higher heights are designed to adapt. Although they have a slower working speed, they are suitable for large-scale operations.
The low-frame gantry crane, developed from the dolly crane, features a unique structure. The dolly is a box-shaped structure, the gantry combines a box-shaped bench structure with a cylinder structure, and the turntable is an integral box structure. The jib adopts a truss-type single jib structure, and the luffing mechanism uses a pulley group wire rope compensation. The rotary support device utilizes a standard large-diameter slewing bearing, while the luffing balance system adopts a lever-live pair heavy-duty type.
Key Features:
- Practicality with the ability to use grabbing buckets and hooks simultaneously.
- Precision in horizontal amplitude change through rack and pinion technology.
- 360° rotation of the working device for a wide operational range.
- Stable and reliable operation with PLC control and AC frequency conversion speed regulation.
- Optional remote monitoring system based on user requirements.
- Complete safety protection devices and a communication lighting system ensure a secure working environment.
Technical Parameters
| Lifting Capacity (t) | 3.2 | 5 | 10 | 16 | 20 | 30 | 40 |
| Lifting Height (m) | -6~12 | -6~11 | -8~10 | -6~11 | -5~13 | -4~14 |
| Lifting Speed (m/min) | 36 | 32 | 36 | 31 | 33.6 |
| Luffing Speed (m/min) | 15 | 10 | 16.5 | 15 | 10 | 12 |
| Slewing Speed (m/min) | 1.4 | 1.46 | 1.2 |
| Boom Length (m) | 12 | 14 | 16 |
| Grab Capacity (m³) | 1 | 1.5 | 2 | 3 | |
| Power Supply Voltage | 380V |
Product Picture
FAQ
1. Q: Can this type work in hazardous environments?
A: Sure! We can customize it for you, acid-proof or explosion-proof, no problem with that.
2. Q: Can you provide the serious lifting tools?
A: Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. Q: How can we install the crane?
A: Our senior engineer can be on your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Q: Safety device
A: Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
